The Panasonic Lumix BS1H camera offers outstanding image quality with its 24.2MP full-frame sensor and versatile recording options up to 5.9K, ensuring detailed and vibrant footage. Its dual-native ISO and 14+ stops of dynamic range capture exceptional detail in varying light conditions. Ideal for mobile and multi-camera setups, it supports Ethernet control, PoE+, and simultaneous HDMI/SDI output. Compact yet durable, it's perfect for creative professionals seeking flexibility and high performance in a lightweight package.
Features
The Panasonic Lumix BS1H offers an impressive set of benefits for photographers and videographers alike.
Exceptional Image Quality
With a 24.2MP full-frame sensor and 14+ stops of dynamic range, the camera delivers stunning image quality even in challenging lighting conditions.
Advanced Video Capabilities
Record up to 5.9K video with dual-native ISO for low-light performance, and enjoy VFR up to 180 fps for smooth slow-motion footage.
Versatile Connectivity
Features like Ethernet with PoE+, Wi-Fi, and Bluetooth offer seamless integration into multi-camera setups and remote control capabilities.
Compact and Durable Design
The magnesium and aluminum body is both lightweight and robust, making it ideal for drones and gimbals.
Professional-Grade Audio
Includes high-grade audio recording options and supports professional microphones with an optional XLR adapter.
Specifications
Lens Mount
Leica L
Interchangeable Lens Mount
None
Lens Communication
Yes
Sensor Resolution
Effective: 24.2 Megapixel
Sensor Type
35.6 x 23.8 mm (Full-Frame) CMOS
Sensor Windowing
6K (5952 x 3968) in 3:2 5K (5888 x 3312) in 16:9 5K (5376 x 3584) in 3:2 4K (4096 x 2160) in 17:9 4K (3840 x 2160) in 16:9 1080p (1920 x 1080) in 16:9
Built-In ND Filter
None
ISO Sensitivity
100 to 51,200 (Native) 80 to 204,800 (Expanded)
Shutter Speed
1/16000 to 1/2 sec
Advertised Dynamic Range
14 Stops
White Balance
2500 to 10,000K
Internal Recording
Recording Modes
H.265/H.265 Long GOP/MOV 4:2:2 10-Bit: 4096 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s) 3840 x 2160p at 23.98/25/29.97 fps (100 to 400 Mb/s) 3328 x 2496p at 23.98/24/25/29.97 fps (150 to 400 Mb/s) 1920 x 1080p at 23.98/29.97/59.94 fps (100 to 200 Mb/s) 1920 x 1080i at 50/59.94 fps (50 to 100 MB/s) H.265/H.265 Long GOP/MOV 4:2:0 10-Bit: 5952 x 3968p at 23.98/24/25 fps (200 Mb/s) 5376 x 3584p at 25/29.97 fps (200 Mb/s) 5888 x 3312p at 23.98/25/29.97 fps (200 Mb/s) 4096 x 2160p at 23.98/24/29.97/48/50/59.94 fps (200 Mb/s) H.265/H.265 Long GOP/MOV 4:2:0 10-Bit: 1920 x 1080p at 100/119.88 fps (150 Mb/s) 1920 x 1080p at 47.95/48 fps (100 Mb/s)
4:2:2 10-Bit via HDMI: 4096 x 2160p at 24/25/30/50/60 fps 3840 x 2160p at 24/25/30/50/60 fps 3240 x 2160p at 24/25/30/50/60 fps 2880 x 2160p at 24/25/30/50/60 fps 1920 x 1080p at 24/25/30/50/60 fps 4:2:2 8-Bit via HDMI: 4096 x 2160p at 24/25/30/50/60 fps 3840 x 2160p at 24/25/30/50/60 fps 3240 x 2160p at 24/25/30/50/60 fps 2880 x 2160p at 24/25/30/50/60 fps 1920 x 2160p at 24/25/30/50/60 fps 4:2:2 10-Bit via SDI/BNC: 1920 x 1080p at 24/25/30/50/60 fps 1920 x 1012p at 24/25/30/50/60 fps 1620 x 1080p at 24/25/30/50/60 fps 1440 x 1080p at 24/25/30/50/60 fps 4:2:2 8-Bit via SDI/BNC: 1920 x 1080p at 24/25/30/50/60 fps 1920 x 1012p at 24/25/30/50/60 fps 1620 x 1080p at 24/25/30/50/60 fps 1440 x 1080p at 24/25/30/50/60 fps
Raw Output
HDMI In Full Frame Mode: 5888 x 3312 12-Bit at 23.98/25/29.97 fps HDMI In Super35 Mode: 4128 x 2176 12-Bit at 23.98/25/29.97/50/59.94 fps 3536 x 2656 12-Bit at 23.98/25/29.97/50 fps
IP Streaming
RTP, RTSP: 1280 x 2160 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 50.00 Mb/s)
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]
Video Connectors
1 x BNC (3G-SDI) Output 1 x HDMI (HDMI 2.0) Output
Audio Connectors
1 x 1/8" / 3.5 mm Stereo Mic/Line Level Input on Camera Body 1 x 1/8" / 3.5 mm Stereo Headphone Output on Camera Body
Built-In Microphone Type
Stereo
Other I/O
1 x USB Type-C Camera Interface, USB 3.1 Gen 1 Data, Control, Video Input 1 x BNC Timecode Data Input/Output 1 x BNC Genlock Data Input/Output 1 x RJ45 LAN Control, Monitor, Video Input/Output 1 x 2.5 mm LANC Control Input
Wireless Interfaces
2.4 GHz Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Bluetooth Video Output, Control
Power
Battery Type
Panasonic AG-VBR Series
Power Connectors
1 x Weipu SF610/S2 (12 VDC) Input
PoE Support
PoE+ 802.3at
Environmental
Operating Temperature
14 to 104°F / -10 to 40°C
Operating Humidity
10 to 80%
Physical
Accessory Mount
9 x 3/8"-16 Female 1 x Hot Shoe Mount
Tripod Mounting Thread
2 x 3/8"-16 Female (Bottom)
Material of Construction
Aluminum
Dimensions
3.7 x 3.7 x 3.1" / 9.3 x 9.3 x 7.8 cm (Without Protrusions)
