Name: Canon EOS C80 6K Cinema Camera
Brand: Canon
SKU: C80
Price: 8949.00 NZD
Availability: InStock

Experience exceptional 6K full-frame cinema capture in a compact, lightweight design, perfect for solo operators and fast-paced shooting, with enhanced autofocus, versatile recording options, and compatibility with Canon RF lenses for superior image quality and flexibility, all while benefiting from advanced features like a motorized ND filter wheel, dual SD card slots, Wi-Fi control, and professional audio inputs for a comprehensive and adaptable filmmaking experience.

Features

Exceptional 6K Full-Frame Capture

Experience high-quality 6K30 full-frame video capture with the Canon EOS C80, offering improved light capture for low noise and better 4K imagery through 6K oversampling.

Versatile Recording Options

Benefit from multiple recording formats, including full-frame 6K30, 4K60, and oversampled 4K 120p or 2K 180p, all with 4:2:2 10-bit color, ensuring flexibility in post-production.

Advanced Autofocus and Lens Compatibility

Enjoy improved Dual-Pixel CMOS AF II technology and compatibility with Canon's RF lenses for reliable autofocus and enhanced image stabilization.

Comprehensive Connectivity

Utilize multiple interfaces such as 12G-SDI and HDMI for simultaneous video output, along with USB-C, Ethernet, and Wi-Fi options for remote control and connectivity.

Compact and Ergonomic Design

The lightweight design features a tilting LCD, dual SD card slots, built-in ND filters, and a multi-accessory hot shoe, making it perfect for solo operators and fast-paced shoots.

Specifications

Imaging

Lens Mount	Canon RF
Lens Communication	Yes, Cooke /i
Sensor Resolution	Actual: 26.67 Megapixel (6202 x 4300) Effective: 19.05 Megapixel (6008 x 3170)
Image Sensor	Full-Frame BSI Stacked CMOS
Image Stabilization	Digital, 5-Axis
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters
Internal Filter Holder	No
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1 Second
ISO Sensitivity Range	100 to 102,400
Shutter Angle	11.25 to 360°
Advertised Dynamic Range	16 Stops
Signal-to-Noise Ratio	67 dB
White Balance	2000 to 15,000K Presets: AWB, Daylight, Set A, Set B, Tungsten

Video Capture

XF-HEVC S Long GOP 4:2:2 10-Bit
Internal Recording Modes	Cinema RAW Light 12-Bit UHD 6K (6000 x 3164) at 23.98/24.00/25/29.97 fps [553 to 639 Mb/s] 4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps [293 to 678 Mb/s]
Resolution	4096 x 2160 at 50/59.94/120 fps [225 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [135 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s]
XF-HEVC S Long GOP 4:2:0 10-Bit
Resolution	4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps [35 Mb/s]
XF-HEVC S Long GOP 4:2:0 8-Bit
Resolution	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1280 x 720 at 23.98/24.00/25/50/59.94 fps [6 Mb/s]
XF-AVC S Intra 4:2:2 10-Bit
Resolution	4096 x 2160 at 59.94/60.00 fps [600 Mb/s] 3840 x 2160 at 50/60.00 fps [500 Mb/s] 2048 x 2160 at 59.94/120 fps [300 Mb/s] 1920 x 1080 at 50/120 fps [250 Mb/s]
XF-AVC S Intra 4:2:2 10-Bit
Resolution	4096 x 2160 at 50/59.94/120 fps [250 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [150 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [50 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [120 to 300 Mb/s]
XF-AVC S Long GOP 4:2:0 8-Bit
Resolution	4096 x 2160 at 50/59.94/120 fps [150 Mb/s] 3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s] 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
XF-HEVC S Intra 4:2:0 8-Bit
Resolution	2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s] 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s] 1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps [6 Mb/s]
External Recording Modes	SDI/BNC / HDMI / USB 4096 x 2160
Recording Sensor Crop	Crops to Output Resolution When Using Super35 Mode
Fast-/Slow-Motion Support	Yes
Gamma Curve	Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020
Broadcast Output	NTSC/PAL

Audio

Built-In Microphone	Stereo
Audio Recording	Cinema RAW Light: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 4-Channel 24-Bit 48 kHz LPCM Audio XF-AVC S, XF-HEVC S: 2-Channel 16-Bit 48 kHz AAC Audio

Streaming

IP Streaming	H.264, MPEG2, RTP, RTSP, SRT, UDP 1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s)

Still Image Capture

Image File Format	JPEG

Interface

Video I/O
Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Connections	1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Monitor Output 1x HDMI (Unspecified Signal) Output
Audio I/O
Connections	2x Mini XLR Input 1x 1/8" / 3.5 mm TRS Stereo Headphone Output 1x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body
Power I/O
Connections	1x Barrel (23.7 to 25VDC) Input
Other I/O
Connections	1x RJ45 (XC) Control 1x USB-C Monitor 1x BNC (Timecode) 1x 2.5 mm Sub-Mini (LANC) Control

Wireless

Wireless	2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible	Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Included External Touchscreen LCD
Display Size	3.5"
Resolution	1280 x 720

Focus

Focus Type	Auto and Manual Focus
Focus Mode	Continuous-Servo AF, Focus Lock AF Area Mode, One-Shot AF

General

Operating Conditions	32 to 104°F / 0 to 40°C up to 85% Humidity
Storage Conditions	23 to 113°F / -5 to 45°C up to 60% Humidity
Battery Type	Canon BP-AN Series
Shoe Mount	1x Intelligent Hot Shoe
Tripod Mounting Thread	1x 3/8"-16 Female 2x 1/4"-20 Female
Accessory Mounting Thread	No
Dimensions (W x H x D)	6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm 10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder)
Weight	2.87 lb / 1.30 kg (Body Only) 3.406 lb / 1.545 kg (With Battery, Handle)
